Fixed Wavelength Semiconductor Laser【FLM】

Fixed Wavelength Semiconductor Laser FLM  Specifications

Model	FLM-****　(Specified Wavelength)
Setting wavelength	1180-1370nm/1400-1680nm ※Please specify a necessary wavelength
Wavelength accuracy	≦±０．２ｎｍ
Optical output power※1	≧＋１０ｄＢｍ
Spectrum linewidth(Typ.)※2	≦３０ｋＨｚ(Min.：≦１０ｋＨｚ)
ＲＩＮ(Typ.)※2	≦－１５０ｄＢ／Ｈｚ
Frequency stability※3	≦±１００ＭＨｚ (60min.)＝±0.8pm (Wavelength stability)
Optical output power stability※3	≦±０．０３ｄＢ (60min.)
Output optical fiber	Polarization Maintaining Fiber ※Optical connectors are selectable.
Polarization	Linear polarization, aligned to the connector key, Extinction ratio≧２０ｄＢ (Typ.)
Dimensions	５０Ｗ×７５Ｄ×２９Ｈ

＜Contents are subject to change without notice.＞
※1： Max. output power changes depending on the model/wavlength.
※2： To achieve narrow linewidth and low RIN, connect a highly stable power supply and driver.
※3： In the constant environment (Measurement by using our facilities＜Power supply・Driver＞)
